Article By Steve Gatcomb



Obsolescence can occur in any equipment with significant cost impact on the ability to continue using both existing and historically provided products.
Replacement of obsolete components can require extensive evaluation and testing to verify the replacement component meets the initial design and qualification requirements.
Valcor recently experienced one such event as a chemical compound used to make critical O-rings for nuclear service valves was no longer available. These O-rings are located in both the valve and actuator assemblies and loss of coolant serve as static and dynamic seals. These seals were initially designed and qualified to meet the stringent requirements of IEEE-323, 344 and 382 to withstand the effects of extended life and design basis accidents, e.g., seismic events and loss of coolant accidents.
Two options
The seals inside the valve’s pressure boundary can be static, dynamic, or both. Additionally, they can be used as a “soft seat” on the poppet and disc assemblies providing bubble-tight shut-off.
The seals for the actuator assembly are static and are required to maintain the NEMA 4 rating of the actuator. Both the actuator and valve assembly seals are exposed to temperature, heat, radiation and cyclic (for dynamic seals) loads.
In solving this obsolescence issue, Valcor worked closely with the O-ring manufacturer to identify different O-ring compounds that could meet or exceed the original material specifications and performance characteristics.
A comprehensive analysis of the performance characteristics was performed, identifying two potential replacement compounds. This analysis looked at the critical characteristics of heat, radiation, pliability, wear, and maintainability.
Static and dynamic seals
Valcor manufactured six identical solenoid operated valves (SOVs) that used both static and dynamic O-ring seals. These SOVs were used as test articles for evaluating the potential new O-rings.
Both new O-ring compounds were installed in each of two SOVs, and the original O-ring compound installed in the final two SOVs. Key performance objectives included, but were not limited to: leakage, pliability, ease of assembly/disassembly, heat, and radiation resistance.
To verify the design analysis and assumptions, a complete qualification program was developed using the guidance of IEEE-323 (Standard for Qualifying Class 1E Equipment for Nuclear Power Generating Stations). The six test article SOVs then went through the qualification program using the following test sequence: Initial Inspection, Baseline Functional Testing, Thermal ageing, Intermediate Function Testing, Cycle Aging (First Half), Radiation Aging (2.2 × 108 Rads), Intermediate Function Testing, Cycle Aging (Second Half), Final Functional Testing, and Final Inspection.
Upon completion of these tests, results were tabulated and evaluated. Valcor determined that one of the two potential replacement O-ring compounds performed as well as or better than the now-obsolete O-ring material.
Therefore, it was deemed suitable to replace the obsolete O-ring material. It must be noted the selection of the replacement O-ring material was not a forgone conclusion, but the result of substantial efforts for product evaluation, testing, and verification performed.
These exercises occur more often as obsolescence issues take place on equipment that is designed to last forty to sixty years or longer. The cost associated with replacing obsolete components contained within a product must be compared to the replacement cost of the product itself, as opposed to the cost of replacing the product with a new design. The risk here is that any component of the new design could be easily obsoleted before reaching the design life expectancy of the new product.
Long-term commitment
However, if the obsoleted component requires replacement as part of a preventative or periodic maintenance program, then the cost of change may be marginal. In many instances, the end-user of the equipment must be willing to share these costs with the procurement company as it affects their cost of operation. Depending on the difficulty in replacing the obsoleted component, efforts of this magnitude can easily exceed six figures and require a long-term commitment from both the manufacturer of the equipment and the end-user.
