The Compact Style Single Ball Valves are designed to provide considerable space and weight savings when compared to a traditional flanged end ball valve. Available in both floating and trunnion ball designs, the valve utilises Oliver’s proven ball valve technology and can be supplied with either manual or automated actuation.
Bi-Directional Single Ball Valve with soft or metal seats; Swivel flange type construction, with butt weld hub connections; and Floating Ball or Trunnion mounted design
The compact light weight design provides space and weight saving on platforms, reduced shipping and handling costs, and minimal structural support.
The threaded valve insert is designed to take full working pressure and it does not rely on the mating flange to hold internals.
The Oliver swivel Flanges are designed to allow hubs to be welded into line before split rings and flanges are fitted. The valve can be fitted with no additional ‘springing’ of pipework.
The firesafe design is O-ring seals and metal-to-metal contact on all static joints, graphite rings provide additional resistance to leakage in the vent of fire.
Anti-blow out stem design shouldering on the body (rather than the bonnet), automatic cavity relief, low friction dry stem bearings to minimise operating torques and maximise cycle life.
The valves can be supplied with a mounting plate in accordance with ISO 5211 for actuator attachment.
